Contour Recessed is a recessed linear lighting system available in a range of lengths from 600mm to 1800mm. Finished in a classic white the aluminium extruded precision cut body features a recessing flange. The low glare polycarbonate diffuser can be specified in opal or micro prism with flush die-cast aluminium end-caps for a completely durable finish.
Low glare opal polycarbonate diffuser (Micro-prism available) with flush die-cast aluminium endcaps
High and Low Output variations available in 600 1200 1500 & 1800mm lengths
Continuous homogeneous recessed lighting system with up to 107 Llm/cW fixed output or dimmable drivers available along with full range of lit connectors
Suitable for recessed mounting in plasterboard with flange design plug and play wiring for continuous connection
Additional Product Options
We offer additional product options to give ultimate control and flexibility to match any application
DALI Digital Dimming
DALI Digital Dimming offers precise control of individual fixtures and groups of lights, which can lead to decreased energy consumption and saved running costs. All options are available as DALI dimmable Insert D, eg. LCOT12WO12D40
3hr Emergency
3-hour Emergency feature guarantee's that in the event of a power outage, the lights will remain illuminated for an extended period of time, enabling a safe exit. This can be critical for safety reasons, allowing people to exit a building safely in the event of an emergency. All modules with exception of 600mm length are available with three hour emergency. Insert E, eg. LCOT12WO12E40
Self-Test Emergency
Emergency lighting is required to allow safe evacuation of an area in the event of mains failure. Luceco's self-test emergency pack provides 3 hours worth of back-up power whilst the pack checks itself automatically to ensure that the battery and lamp in each emergency light are fully operational to meet all standards and regulations.
DALI Addressable Emergency
Emergency lighting is required to allow safe evacuation of an area in the event of mains failure. Luceco's DALI addressable emergency pack provides 3 hours worth of back-up power, the pack automatically monitors itself to ensure that the battery and lamp in each emergency light are fully operational along with recording valuable data to meet all standards and regulations.
3000K Colour Temperature
3000K light provides a warmer more comforting effect that can be preferred in many of applications including certain public areas and domestic settings.
Code | Base Colour | Unpacked Depth (mm) | Driver Type | Lumen Output (lm) | Max Wattage (W) | Efficacy (Lm/W) | Add to Spec |
---|---|---|---|---|---|---|---|
Code
LCOT06WO06S40
|
Base Colour
White - RAL 9016 (Traffic White)
|
Unpacked Depth (mm)
602
|
Driver Type
Fixed Output
|
Lumen Output (lm)
600
|
Max Wattage (W)
6
|
Efficacy (Lm/W)
100
|
|
Code
LCOT06BO06S40
|
Base Colour
Black - RAL9005 (Jet Black)
|
Unpacked Depth (mm)
602
|
Driver Type
Fixed Output
|
Lumen Output (lm)
600
|
Max Wattage (W)
6
|
Efficacy (Lm/W)
100
|
|
Code
LCOT12WO12S40
|
Base Colour
White - RAL 9016 (Traffic White)
|
Unpacked Depth (mm)
1162
|
Driver Type
Fixed Output
|
Lumen Output (lm)
1250
|
Max Wattage (W)
12
|
Efficacy (Lm/W)
104
|
|
Code
LCOT12BO12S40
|
Base Colour
Black - RAL9005 (Jet Black)
|
Unpacked Depth (mm)
1162
|
Driver Type
Fixed Output
|
Lumen Output (lm)
1250
|
Max Wattage (W)
12
|
Efficacy (Lm/W)
104
|
|
Code
LCOT15WO15S40
|
Base Colour
White - RAL 9016 (Traffic White)
|
Unpacked Depth (mm)
1442
|
Driver Type
Fixed Output
|
Lumen Output (lm)
1600
|
Max Wattage (W)
14
|
Efficacy (Lm/W)
114
|
|
Code
LCOT15BO15S40
|
Base Colour
Black - RAL9005 (Jet Black)
|
Unpacked Depth (mm)
1442
|
Driver Type
Fixed Output
|
Lumen Output (lm)
1600
|
Max Wattage (W)
14
|
Efficacy (Lm/W)
114
|
|
Code
LCOT18WO18S40
|
Base Colour
White - RAL 9016 (Traffic White)
|
Unpacked Depth (mm)
1723
|
Driver Type
Fixed Output
|
Lumen Output (lm)
1900
|
Max Wattage (W)
18
|
Efficacy (Lm/W)
106
|
|
Code
LCOT18BO18S40
|
Base Colour
Black - RAL9005 (Jet Black)
|
Unpacked Depth (mm)
1723
|
Driver Type
Fixed Output
|
Lumen Output (lm)
1900
|
Max Wattage (W)
18
|
Efficacy (Lm/W)
106
|
