Epsilon
The Luceco Epsilon is a range of direct : indirect LED panels with Opal and Microprism options available.
A direct: indirect recessed luminaire Epsilon is manufactured with a robust steel body finished in RAL9016. With dimensions of 595 x 595 the Epsilon solutions are recessed mounted and suitable for use in 15 or 24mm standard exposed grid ceilings. Epsilon is available with a choice of lumens between 2500 to 4200 allowing for an option to best suit the needs of the application. The IP40 and IK04 ratings offer added protection, with the backing of a 5-year warranty.
600 x 600mm Recessed-mounted luminaire suitable for use in 15 or 24mm standard exposed grid ceilings
Direct / Indirect recessed led luminaires ranging from 2500 to 4200 Lumens with efficacy up-to 120 Llm/cW
Opal diffuser or micro-prism optic variations available designed for full LG7 compliant designs less than 3000Cd/m2 above 65 degrees
Additional Product Options
We offer additional product options to give ultimate control and flexibility to match any application
Remote Emergency
Emergency lighting is required to allow safe evacuation of an area in the event of mains failure. Luceco's remote emergency pack provides 3 hours worth of back-up power to enable this to happen meeting all standards and regulations. Product Code; LED3EP80
Self-Test Emergency
Emergency lighting is required to allow safe evacuation of an area in the event of mains failure. Luceco's self-test emergency pack provides 3 hours worth of back-up power whilst the pack checks itself automatically to ensure that the battery and lamp in each emergency light are fully operational to meet all standards and regulations. Product Code; LED3EP80EST
DALI Addressable Emergency
Emergency lighting is required to allow safe evacuation of an area in the event of mains failure. Luceco's DALI addressable emergency pack provides 3 hours worth of back-up power, the pack automatically monitors itself to ensure that the battery and lamp in each emergency light are fully operational along with recording valuable data to meet all standards and regulations. Product Code; LED3EP80DED
| Code | Driver Type | Lumen Output (lm) | Max Wattage (W) | Efficacy (Lm/W) | Standard Deviations of Colour Matching | L/B at Life | Add to Spec |
|---|---|---|---|---|---|---|---|
|
Code
LEP66WO22S40
|
Driver Type
Fixed Output
|
Lumen Output (lm)
2200
|
Max Wattage (W)
18
|
Efficacy (Lm/W)
122
|
Standard Deviations of Colour Matching
<3
|
L/B at Life
L80-B10
|
|
|
Code
LEP66WO22D40
|
Driver Type
Digital Dimmable
|
Lumen Output (lm)
2200
|
Max Wattage (W)
18
|
Efficacy (Lm/W)
122
|
Standard Deviations of Colour Matching
<3
|
L/B at Life
L80-B10
|
|
|
Code
LEP66WO30S40
|
Driver Type
Fixed Output
|
Lumen Output (lm)
3000
|
Max Wattage (W)
26
|
Efficacy (Lm/W)
115
|
Standard Deviations of Colour Matching
<3
|
L/B at Life
L80-B10
|
|
|
Code
LEP66WO30D40
|
Driver Type
Digital Dimmable
|
Lumen Output (lm)
3000
|
Max Wattage (W)
26
|
Efficacy (Lm/W)
115
|
Standard Deviations of Colour Matching
<3
|
L/B at Life
L80-B10
|
|
|
Code
LEP66WO36S40
|
Driver Type
Fixed Output
|
Lumen Output (lm)
3600
|
Max Wattage (W)
33
|
Efficacy (Lm/W)
109
|
Standard Deviations of Colour Matching
<3
|
L/B at Life
L80-B10
|
|
|
Code
LEP66WO36D40
|
Driver Type
Digital Dimmable
|
Lumen Output (lm)
3600
|
Max Wattage (W)
33
|
Efficacy (Lm/W)
109
|
Standard Deviations of Colour Matching
<3
|
L/B at Life
L80-B10
|
