Direct / Indirect alternative to LED panel
Very Efficient LEDs achieving 139Llm/W
UGR<19 as standard
Fixed output control gear
LED3EP80 remote emergency pack compatible with self-est and DALI EM options available
Technical Data
| Code | LEP66WM25S40 |
| Driver Type | Fixed Output |
| Lumen Output (lm) | 2500 |
| Max Wattage (W) | 18 |
| Efficacy (Lm/W) | 139 |
| Colour Temp (CCT) (K) | 4000 |
| CRI | >80 |
| Base Colour | White - RAL 9016 (Traffic White) |
Dimensions and Installation
| Unpacked Depth (mm) | 595 |
| Unpacked Width (mm) | 595 |
| Unpacked Height (mm) | 72 |
| Unpacked Net Weight (kg) | 4.6 |
| IP Rating | IP40 |
| IK Rating | IK04 |
| Cutout (mm) | 585x585mm |
Performance & Safety
| Lifetime (h) | 50000 |
| L/B at Life | L80-B10 |
| L70 Hours (h) | 50000 |
| Operating Temperature (C) | -20°C to +25°C |
| E-Class | Class2 |
| Power Factor | >0.9 |
| UGR 4H 8H | <17 |
| Fire Rating | TPB |
