LuxPanel Anti Ligature

View Product Family

Linear anti-ligature luminaire for use in secure environments, polycarbonate diffuser, tamper resistant screws suppliedas standard

IK10 rated steel body with UV stabilised and fire retardant polycarbonate diffuser

Dimmable, emergency and self-test options available

Code	Driver Type	Lumen Output (lm)	Max Wattage (W)	Efficacy (Lm/W)	Beam Angle (degrees)	Add to Spec
Code LPAL66W35S40	Driver Type Fixed Output	Lumen Output (lm) 3500	Max Wattage (W) 30	Efficacy (Lm/W) 117	Beam Angle (degrees) 120	Add to Spec Remove from Spec Processing
Code LPAL66W35D40	Driver Type Digital Dimmable	Lumen Output (lm) 3500	Max Wattage (W) 30	Efficacy (Lm/W) 117	Beam Angle (degrees) 120	Add to Spec Remove from Spec Processing
Code LPAL66W35E40	Driver Type Fixed Output + Emergency	Lumen Output (lm) 3500	Max Wattage (W) 30	Efficacy (Lm/W) 117	Beam Angle (degrees) 120	Add to Spec Remove from Spec Processing
Code LPAL66W35EST40	Driver Type Self-Test Emergency	Lumen Output (lm) 3500	Max Wattage (W) 30	Efficacy (Lm/W) 117	Beam Angle (degrees) 120	Add to Spec Remove from Spec Processing
Code LPAL66W57S40	Driver Type Fixed Output	Lumen Output (lm) 5700	Max Wattage (W) 48	Efficacy (Lm/W) 119	Beam Angle (degrees) 120	Add to Spec Remove from Spec Processing
Code LPAL66W57D40	Driver Type Digital Dimmable	Lumen Output (lm) 5700	Max Wattage (W) 48	Efficacy (Lm/W) 119	Beam Angle (degrees) 120	Add to Spec Remove from Spec Processing
Code LPAL66W57E40	Driver Type Fixed Output + Emergency	Lumen Output (lm) 5700	Max Wattage (W) 48	Efficacy (Lm/W) 119	Beam Angle (degrees) 120	Add to Spec Remove from Spec Processing
Code LPAL66W57EST40	Driver Type Self-Test Emergency	Lumen Output (lm) 5700	Max Wattage (W) 48	Efficacy (Lm/W) 119	Beam Angle (degrees) 120	Add to Spec Remove from Spec Processing
Code LPAL66W79S40	Driver Type Fixed Output	Lumen Output (lm) 7900	Max Wattage (W) 66	Efficacy (Lm/W) 120	Beam Angle (degrees) 120	Add to Spec Remove from Spec Processing
Code LPAL66W79D40	Driver Type Digital Dimmable	Lumen Output (lm) 7900	Max Wattage (W) 66	Efficacy (Lm/W) 120	Beam Angle (degrees) 120	Add to Spec Remove from Spec Processing
Code LPAL66W79E40	Driver Type Fixed Output + Emergency	Lumen Output (lm) 7900	Max Wattage (W) 66	Efficacy (Lm/W) 120	Beam Angle (degrees) 120	Add to Spec Remove from Spec Processing
Code LPAL66W79EST40	Driver Type Self-Test Emergency	Lumen Output (lm) 7900	Max Wattage (W) 66	Efficacy (Lm/W) 120	Beam Angle (degrees) 120	Add to Spec Remove from Spec Processing
