Technical Data

Code ELP15W9L40
Driver Type Fixed Output
Lumen Output (lm) 720
Max Wattage (W) 9
Efficacy (Lm/W) 80
Colour Temp (CCT) (K) 4000
Beam Angle (degrees) 110
CRI >80
Base Colour White

Dimensions and Installation

Cutout (mm) 135mm
Unpacked Depth (mm) 0
Unpacked Width (mm) 145
Unpacked Height (mm) 19
Unpacked Net Weight (kg) 0.198

Performance & Safety

Lifetime (h) 25000
L/B at Life L70-B50
Operating Temperature (C) -20°C to +25°C
E-Class Class2
Power Factor >0.5
IK Rating IK04
Fire Rating TPB
