Climate Anti Ligature

Robust antiligature linear luminaire suitable for use in secure environments and areas where vandalism may be an issue

IK10 rated steel body with UV stabalised fire retardent polycarbonate diffuser

Tamper resistant screws supplied as standard

Dimmable emergency and self test options all available

Suitable for surface mounting efficacy upto 143Llm/cW and IK10 steel body with Tamper proof screws.

Code	Driver Type	Lumen Output (lm)	Max Wattage (W)	Efficacy (Lm/W)	Beam Angle (degrees)	Add to Spec
Code LCLAL15W49S40	Driver Type	Lumen Output (lm) 4870	Max Wattage (W) 34	Efficacy (Lm/W) 143	Beam Angle (degrees) 120	Add to Spec Remove from Spec Processing
Code LCLAL15W49E40	Driver Type	Lumen Output (lm) 4870	Max Wattage (W) 34	Efficacy (Lm/W) 143	Beam Angle (degrees) 120	Add to Spec Remove from Spec Processing
Code LCLAL15W49D40	Driver Type	Lumen Output (lm) 4870	Max Wattage (W) 34	Efficacy (Lm/W) 143	Beam Angle (degrees) 120	Add to Spec Remove from Spec Processing
Code LCLAL15W98S40	Driver Type	Lumen Output (lm) 9740	Max Wattage (W) 68	Efficacy (Lm/W) 143	Beam Angle (degrees) 120	Add to Spec Remove from Spec Processing
Code LCLAL15W98E40	Driver Type	Lumen Output (lm) 9740	Max Wattage (W) 68	Efficacy (Lm/W) 143	Beam Angle (degrees) 120	Add to Spec Remove from Spec Processing
Code LCLAL15W98D40	Driver Type	Lumen Output (lm) 9740	Max Wattage (W) 68	Efficacy (Lm/W) 143	Beam Angle (degrees) 120	Add to Spec Remove from Spec Processing
