Contour Octa
Suspended direct/indirect lighting system providing low-glare and soft lighting
Contour Octa is an extension to the Contour portfolio of solutions that create suspended linear systems in a range of different configurations and lengths. The system is supplied in a crisp and class white finish and with its OctGo reflector design provides UGR19 compliancy and glare ratings as low as 14 . The luminaire is suspended via a 1.5m suspension kit, offering a 100k hour lifetime and a 5-year warranty, peace of mind is guaranteed with Contour
| Code | Base Colour | Unpacked Depth (mm) | Driver Type | Lumen Output (lm) | Max Wattage (W) | Efficacy (Lm/W) | Add to Spec |
|---|---|---|---|---|---|---|---|
|
Code
LCOO12UDW5W30S40
|
Base Colour
White - RAL 9016 (Traffic White)
|
Unpacked Depth (mm)
1134
|
Driver Type
Fixed Output
|
Lumen Output (lm)
3000
|
Max Wattage (W)
24
|
Efficacy (Lm/W)
125
|
|
|
Code
LCOO12UDW5W30E40
|
Base Colour
White - RAL 9016 (Traffic White)
|
Unpacked Depth (mm)
1134
|
Driver Type
Fixed Output + Emergency
|
Lumen Output (lm)
3000
|
Max Wattage (W)
24
|
Efficacy (Lm/W)
125
|
|
|
Code
LCOO12UDW5W30D40
|
Base Colour
White - RAL 9016 (Traffic White)
|
Unpacked Depth (mm)
1134
|
Driver Type
Digital Dimmable
|
Lumen Output (lm)
3000
|
Max Wattage (W)
24
|
Efficacy (Lm/W)
125
|
|
|
Code
LCOO12UDW5W30ED40
|
Base Colour
White - RAL 9016 (Traffic White)
|
Unpacked Depth (mm)
1134
|
Driver Type
Digital Dimmable + Emergency
|
Lumen Output (lm)
3000
|
Max Wattage (W)
24
|
Efficacy (Lm/W)
125
|
|
|
Code
LCOO12UDW5W50S40
|
Base Colour
White - RAL 9016 (Traffic White)
|
Unpacked Depth (mm)
1134
|
Driver Type
Fixed Output
|
Lumen Output (lm)
5000
|
Max Wattage (W)
40
|
Efficacy (Lm/W)
125
|
|
|
Code
LCOO12UDW5W50E40
|
Base Colour
White - RAL 9016 (Traffic White)
|
Unpacked Depth (mm)
1134
|
Driver Type
Fixed Output + Emergency
|
Lumen Output (lm)
5000
|
Max Wattage (W)
40
|
Efficacy (Lm/W)
125
|
|
|
Code
LCOO12UDW5W50D40
|
Base Colour
White - RAL 9016 (Traffic White)
|
Unpacked Depth (mm)
1134
|
Driver Type
Digital Dimmable
|
Lumen Output (lm)
5000
|
Max Wattage (W)
40
|
Efficacy (Lm/W)
125
|
|
|
Code
LCOO12UDW5W50ED40
|
Base Colour
White - RAL 9016 (Traffic White)
|
Unpacked Depth (mm)
1134
|
Driver Type
Digital Dimmable + Emergency
|
Lumen Output (lm)
5000
|
Max Wattage (W)
40
|
Efficacy (Lm/W)
125
|
|
|
Code
LCOO15UDW5W30S40
|
Base Colour
White - RAL 9016 (Traffic White)
|
Unpacked Depth (mm)
1412
|
Driver Type
Fixed Output
|
Lumen Output (lm)
3000
|
Max Wattage (W)
24
|
Efficacy (Lm/W)
125
|
|
|
Code
LCOO15UDW5W30E40
|
Base Colour
White - RAL 9016 (Traffic White)
|
Unpacked Depth (mm)
1412
|
Driver Type
Fixed Output + Emergency
|
Lumen Output (lm)
3000
|
Max Wattage (W)
24
|
Efficacy (Lm/W)
125
|
|
|
Code
LCOO15UDW5W30D40
|
Base Colour
White - RAL 9016 (Traffic White)
|
Unpacked Depth (mm)
1412
|
Driver Type
Digital Dimmable
|
Lumen Output (lm)
3000
|
Max Wattage (W)
24
|
Efficacy (Lm/W)
125
|
|
|
Code
LCOO15UDW5W30ED40
|
Base Colour
White - RAL 9016 (Traffic White)
|
Unpacked Depth (mm)
1412
|
Driver Type
Digital Dimmable + Emergency
|
Lumen Output (lm)
3000
|
Max Wattage (W)
24
|
Efficacy (Lm/W)
125
|
|
|
Code
LCOO15UDW5W50S40
|
Base Colour
White - RAL 9016 (Traffic White)
|
Unpacked Depth (mm)
1412
|
Driver Type
Fixed Output
|
Lumen Output (lm)
5000
|
Max Wattage (W)
40
|
Efficacy (Lm/W)
125
|
|
|
Code
LCOO15UDW5W50E40
|
Base Colour
White - RAL 9016 (Traffic White)
|
Unpacked Depth (mm)
1412
|
Driver Type
Fixed Output + Emergency
|
Lumen Output (lm)
5000
|
Max Wattage (W)
40
|
Efficacy (Lm/W)
125
|
|
|
Code
LCOO15UDW5W50D40
|
Base Colour
White - RAL 9016 (Traffic White)
|
Unpacked Depth (mm)
1412
|
Driver Type
Digital Dimmable
|
Lumen Output (lm)
5000
|
Max Wattage (W)
40
|
Efficacy (Lm/W)
125
|
|
|
Code
LCOO15UDW5W50ED40
|
Base Colour
White - RAL 9016 (Traffic White)
|
Unpacked Depth (mm)
1412
|
Driver Type
Digital Dimmable + Emergency
|
Lumen Output (lm)
5000
|
Max Wattage (W)
40
|
Efficacy (Lm/W)
125
|
