Technical Data

Code LCO18BO18S40
Driver Type Fixed Output
Lumen Output (lm) 1900
Max Wattage (W) 18
Efficacy (Lm/W) 106
Colour Temp (CCT) (K) 4000
CRI >80
Standard Deviations of Colour Matching <3
Base Colour Black - RAL9005 (Jet Black)
Onsite Warranty Yes

Dimensions and Installation

Unpacked Depth (mm) 1695
Unpacked Width (mm) 60
Unpacked Height (mm) 100
Unpacked Net Weight (kg) 4.32
IP Rating IP40
IK Rating IK04
Cutout (mm) NA

Performance & Safety

Lifetime (h) 100000
L/B at Life L70-B50
L70 Hours (h) 100000
L80 Hours (h) 50000
L90 Hours (h) 25000
Operating Temperature (C) -20°C to +25°C
E-Class Class1
Power Factor >0.9
UGR 4H 8H <22
